Exway Atlas Carbon 2WD 1500W All Terrain Electric Skateboard EB-A12WD
Atlas Carbon 2WD-All Terrain
Features
| Atlas 2WD-All Terrain | Atlas 2WD-2in1 |
|
|
Specifications
| Atlas 2WD-All Terrain | Atlas 2WD-2in1 | |
| Dimensions | 1186×312×160mm（LWH) | 1186×312×160mm（LWH） |
| Weight | 11.5Kg | 11.5Kg |
| Top Speed | 48Km/h | 48km/h (All Terrain) 43km/h (Street) |
| Range | 30Km (All Terrain) | 30km (All Terrain) 54km (Street) |
| Remote | R2 | R2 |
| Battery Capacity | 518Wh | 518Wh |
| Hill Climbing | 35% | 35% |
| Torque | 9N.m*2 | 9N.m*2 |
| Motor Power | 1500W*2 (Rated Motor Power Max. Current) | 1500W*2 (Rated Motor Power Max. Current) |
| Charging Time | 3.5H (Standard Charger) | 3.5H (Standard Charger) |
| Braking | Regenerative Brakes | Regenerative Brakes |
| Truck | Exway DKP 9.5Inch | Exway DKP 9.5inch |
| Waterproof Rating | IP55 | IP55 |
| Warranty | 1 (One) Year | 1 (One) Year |
| Max Load | 100Kg | 100Kg |
| Griptape | Shock-absorbing Griptape | Shock-absorbing griptape |
| Max. Working Distance (Frequency) |
R2 2.4GHz FCC: 10 m CE: 10 m SRRC: 10 m |
R2 2.4GHz FCC: 10 m CE: 10 m SRRC: 10 m |
| Temperature Comfort Zone | 0-40°C | 0-40°C |
| Battery Capacity | 600mAh | 600mAh |
| Remote On-Off | Supported | Supported |
| Tank Mode | Supported | Supported |
| Charger | ||
| Input | 100-240V | 100-240V |
| Output | 51V-4A Standard Charger |
51V-4A Standard Charger |
| Rated Power | 204W Standard Charger |
204W Standard Charger |
| Smart Battery | ||
| Battery Capacity | 518Wh | 518Wh |
| Rated Power | 43.2V | 43.2V |
| Rated Charge Voltage | 50.4V | 50.4V |
| Cell Type | 21700 | 21700 |
| Temperature Comfort Zone | 0-40°C | 0-40°C |
| USB Output Power USB charging output |
- | - |
| Truck | ||
| Size | DKP 9.5inch | DKP 9.5inch |
| Material | Aluminium | Aluminium |
| Angle | - | - |
| Casting | Forged | Forged |
| Power-train | ||
| Power System | Riot | Riot |
| Applicable Belt Size | 255/280/300/340/375 | 255/280/300/340/375 |
| Applicable Pulley Size | 28T/36T/44T/56T/66T | 28T/36T/44T/56T/66T |
| Recommended Wheel Size | 76/80/85/90/96/105/120/150/160/175 | 76/80/85/90/96/105/120/150/160/175 |
